If you are interested in purchasing any of these archive items, please fill out the form below with the necessary details. We will get back to you as soon as possible with availability and pricing information.

All wheels are 100% customizable at Light Bicycle. If your preferred specs are not listed, feel free to contact us (sales@lightbicycle.com) with your special requirements described.


RIM SPECS

  • Use road bike/cyclocross
  • Size 700c
  • Material full carbon Toray T700
  • Type clincher
  • Weight 440g+/-15
  • Tubeless ready
  • Spoke Hole 16H to 36H
  • Internal hole customized
  • ERD 564mm
  • Inner width 15.9mm
  • Outer width 23mm
  • Depth 38mm
  • Max weight limit 115kg
  • Max spoke tension 180kgf
  • Max tyre pressure 160psi
  • Finish matte/glossy
  • Decal customized
  • Weave UD/3K/12K
  • Warranty 15 Months
  • Standard En Standard

Read more for actual road tire width

MTB carbon rim profile

TECH

wider 700c 38mmm clincher cross rims are designed for cyclocross bike & road bike, it is the best choice for cyclo cross wheels, cyclocross bicycles riders. 23mm wider cross wheels rim can be for V-brake & Disc brake.

WARRANTY

For Non-Pro Series Rims: From the date of purchase, 3-year Standard Warranty.

For Pro Series Rims: From the date of purchase, 5-year Pro Warranty as standard and an upgraded optional lifetime Premium Warranty with minimum charge.

Crash Replacement: It is applicable with the same period as the warranty time range that you purchased for the rims with 10% /25% discount for Non-Pro series /Pro series.

Overview

Specs

Warranty

In The Box

wider 700c 38mmm clincher cross rims are designed for cyclocross bike & road bike, it is the best choice for cyclo cross wheels, cyclocross bicycles riders. 23mm wider cross wheels rim can be for V-brake & Disc brake.

Gallery

Add a comment...
Australia
0
Giant : wider 700c 38mm clincher carbon rims for cyclocross bikes road bike
France
1
Paal : 38mm wheelset: 23mm wide rims, UD, matte, without braking track Novatec D711/D712 hub black spokes green nipples
Norway
1
Benjamin : The 38mm rims easily converted to tubeless using just yellow tape and a valve. I used Specialized Roubaix tubeless tires. They were an extremely tight fit, but inflated right up. I have put quite a few miles on them now without any problems. 38mm clincher 23mm wide, UD, matte, 32holes, without braking track
USA
1
Chandra : Some photos of my cross bike built with LB's gorgeous wheels. I haven't tried the wheels off road yet but superb handling without any problem so far.
Indonesia
1
P : I love my new wheels! 38mm UD matt Carbon with aero spokes and disc brakes These are set up with tubeless Schwalbe Ultremos Picture: Norway
Norway
1
Bernhard : Light Bicycle 38mm Carbon Clincher build on DTswiss 240s Disk Hubs on my new Steel Disk CX Frame. Amazing Wheels!
Switzerland
1
Al : carbon 38mm clincher wheelset Rims : 23mm width, UD, matte and front 20H/rear 24H Hubs: black Bitex RAF10/RAR9 Spokes: black pillar psr x-tra 1420 aero Nipples: black Basalt braking surface Wheel set weight (total): 1267g not inc skewers. 1307 inc Planet X carbon and ti skewers.
UK
5

View More Reviews >>

COMMENTS

E

Eddie 2016/10/28

we also have new 25m wide U-shaped 35mm clincher rim. It is much wider and stronger. Do you like it? The price is USD163/pcs. Yes i like this one. where do you ship from.

Light-Bicycle 2016/10/28

Hello Eddie, Hello Eddie, Thanks for your inquiry. All rims are hand-made in our own factory in Xiamen China and be shipped out from here directly. Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

W

Wize 2016/10/15

I need a 700c disc rim than can fit 700cx38 tyre. What would be the recommendation?

Light-Bicycle 2016/10/17

Hello Wize, Thanks for your inquiry. We’d like to recommend the 25mm wide 35mm depth for cyclocross riding. It is much wider and stronger. Rim profile attached for reference. The internal width is about 18mm which would work well with 38c tires or narrower road tires. The clincher bead will handle the pressure well. Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

T

tommy 2016/06/10

Hi 35mm depth clincher 25mm width price usd163 include postage to Cebu City Philippines 6000? Usd163 is expensive mostly in ebay now at usd130 price with postage, Pls lower the price? Im using 38mmdepth 20.5mmwidth disc rim now so if i buy will order different spokes? Im using novatec d722sb. Pls advise. Thanks

Light-Bicycle 2016/06/11

Hello Tommy, Thanks for your inquiry. The U35mm depth rim is $163/pcs. Shipping with EMS to Philippines is $33.3. Your total comes to $371.88 USD plus paypal fee. Normally, you need to get some new spokes, because the rim ERD is different, the spoke length will be different. The U35mm rim ERD is 569mm (not including nipple head dimension). The rim quality of different factories are different. Also, some trading companies are not factory, they just sell the stock rims of other factories. For stock rims, they are always with cosmetic problem, or not with good strength, or they are the return parts. If you buy the rims with bad quality, you have to take much time to rebuild the wheels. Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

D

David 2016/03/30

What tubeless tape width should I use for this rim? The inner width of the rim is 15.40mm, but the narrowest tubeless tape I can find is 19mm. Thanks.

Light-Bicycle 2016/03/31

Hi David, This is Carolin from Light Bicycle. Thanks for your inquiry. There are 2 kinds of road rims here currently. One is V shape with 23mm outer width(old design) and the second one is U shape with 25mm outer width(new design). The U shape rim will be more durable and stronger than the V shape rim. 38mm depth is V shape, I recommend you 35mm depth U shape rim. Please find the attached cross-section drawing of the rims. RR38C02:V-shape, $159/pcs, 400 /-15g, use 12~14mm rim tape RRU35C02: U-shape, $163/pcs, 435 /-15g, use 12~16mm rim tape 19mm width rim tape is too wide for our road rims. Could you please find narrower rim tape from other place, such as eBay? For tubeless, you could use a kind of yellow tape, sealant and tubeless tire. Then it works perfectly. Thanks, Lightbicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

C

Charlie 2015/01/26

I'm interested in the 700c 38mm clincher rims with UD finish. Do you offer a the rim with a basalt braking surface?

Light-Bicycle 2015/01/28

Hi Charlie, This is Carolin from Light-Bicycle. Thanks for your inquiry. Currently, there is a new 35mm depth U shaped clincher rim. The rim weight is 420 /-15g and the price is USD163/pcs for a single rim. This rim is stronger than the 38mm depth rim. I recommend you the 35mm depth. Please find the attached cross-section drawing of rims. Is it OK for you? https://www.lightbicycle.com/carbon-700C-25mm-wide-road-rim-clincher-35mm-deep-U-shape-tubeless-compatible-basalt-braking-surface.html For the rims(UD, with basalt braking surface), do you prefer matte or glossy? Front 20 spoke holes/rear 24 spoke holes? http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ Thanks, Light-bicycle

A

Al 2015/10/08

I'm also interested in a 38mm clincher UD finish rim to replace a rim from a set i own. Are there issues with the braking surface of these rims not being durable enough? I can't use the 35mm U shaped rim you're suggesting if I want to reuse the Sapim spokes and DThubs that came with the wheelset;

Light-Bicycle 2015/10/15

Hello Al, Thanks for your inquiry. We have changed the braking surface and it is with basalt braking surface now. It is more durable and greatly improving braking surface performance and rim strength. Thanks for your trust. Have you ever ordered the 38mm rims from us? If not, you also need to get some new spokes. RR38C02 (23mm wide 38mm clincher rim): 430 /-15g, USD159/pcs Please find attached rim profile. Rim weave in UD matte? Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

A

Artron 2015/05/10

Hi there LB, 38mm clinchers in 3K matte, 28/32 pattern (rims only). How to supply to Australia? What is your leadtime? Kind regards, Arron

Light-Bicycle 2015/05/11

Hello Artron, Thanks for your inquiry. For rims, we also have new 25mm wide U-shaped 35mm clincher rims. It is much wider and stronger. Do you like it? Most of our customers chose this one, and it is with good feedback. RRU35C02 (25mm wide U-shaped 35mm clincher rim): 420 /-15g, USD163/pcs RR38C02 (23mm wide 38mm clincher rim): 430 /-15g, 159/pcs Please find attached rims cross-section drawing. It is ok to do 3k matte & 28H/32H. Do you need the braking surface on rims? Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

M

Mark 2015/05/03

I need a pair of carbon clincher rims. These will go on a disc wheel....so no brake tracts!!!. What do you have in 24 spoke count? I want as lifght as possible.

Light-Bicycle 2015/05/04

Hello Mark, Thanks for your inquiry. For rims, we also have new 25mm wide U-shaped 35mm clincher rim. It is much wider and stronger. Do you like it? Please find attached rim cross-section drawing. RRU35C02 (25mm wide U-shaped 35mm clincher rim): 430 /-15g, USD163/pcs RR38C02 (23mm wide U-shaped 38mm clincher rim): 430 /-15g, USD159/pcs For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? Please find below link. http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ No braking surface is ok. Do you like 24H for front & rear? Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

E

Eddy 2014/12/13

Hi, is the following available before I make my order? 23mm x 38mm UD Matt 18 holes and 24 holes? Post to Singapore

Light-Bicycle 2014/12/15

Hello Eddy, Thanks for your inquiry. RR38C02 (23mm wide 38mm clincher rim): 430 /-15g, USD159/pcs Please find attached rim cross-section drawing. It is ok to do UD matte & front 18H/ rear 24H. Currently, we also have new 25m wide U-shaped 35mm clincher rim. It is much wider and stronger. Do you like it? The price is USD163/pcs. The shipping cost is USD33.3 for two rims to Singapore by EMS. Thanks, Light-bicycle

E

Eddy 2014/12/15

Hi, If I choose UD Matt for the rim finish , will the RIM BED be in 3k weave? This is important. Because the carbon strands at the spoke holes will fray when if the RIM BED is in UD finish.

Light-Bicycle 2014/12/17

Hello Eddy, Thanks for your inquiry. RR38C02 (23mm wide 38mm clincher rim): 430 /-15g, USD159/pcs Please find attached rim cross-section drawing. It is ok to do UD matte & front 18H/ rear 24H. Currently, we also have new 25m wide U-shaped 35mm clincher rim. It is much wider and stronger. Do you like it? The price is USD163/pcs. The shipping cost is USD33.3 for two rims to Singapore by EMS. Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

C

Carlo 2014/12/16

Can the rims be built with small 2mm spoke holes for internal nipples?

Light-Bicycle 2014/12/17

Hello Carlo, Thanks for your inquiry. The rims can be manufactured with internal nipples hole (2mm), and we can build the wheelset as following specs. Rims: 23mm wide 38mm clincher rims, 430 /-15g, with internal nipples hole. Please find attached rim cross-section drawing. For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? Front 20H/ rear 24H? Please find below link. http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ Hubs: We have two hubs below. Which do you prefer? Novatec A291/F482 for Shimano 8/9/10 (320g/pair, qr skewers come together with hubs, black/ red/ white) Bitex RAF10/ RAR9 for Shimano 8/9/10 (258g/pair, no qr skewers included, black) Spokes: Black, Pillar Aero X-TRA 1420 aero Wheelset weight (with Novatec hubs): 1378 /-25g, USD548/pair Wheelset weight (with Bitex hubs): 1316 /-25g, USD548/pair Currently, we also have new 25mm wide U-shaped 35mm wheelset. It is much wider and stronger. Do you like it? The price is USD556/pair. The shipping cost is USD58 for one wheelset to Australia by EMS. Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

J

joga 2014/12/06

Hi , Interested in this wider-700c-38mm-clincher-carbon-rims-for-cyclocross. Some spec : - 12 K matter finish with brake track - Hub 10-11 speed sram/shimano - Novatec D711/712SB black . (Any other recomended hub?) Is possible to custom decal the hub to just black and white? - Black aero spoke ,any recommend option? 20/24 or 24/24 - How much add cost for custom decal? Its simply word / accent in white color And how will be the finishing decal? - How much total include cost to Indonesia? Request for special declare price ya Thanks

Light-Bicycle 2014/12/09

Hello Joga, Thanks for your inquiry. We can build the 38mm clincher wheelset as following specs for you. Rims: 23mm wide 38mm clincher rims, 12k matte, with basalt braking surface, 430 /-15g. Please find attached rim cross-section drawing. Hubs: Black, Novatec front D711 standard qr/ rear D712-135mm standard qr. Do you prefer freehub Shimano 10, Shimano 11s or Sram xx1? Because we can not make sure that Shimano 11s and Sram xx1 are compatible. May I know your weight? Then we can check if D711/D712 are strong enough. Please find attached hub color. Is that what you like? Spokes: Black, Pillar Aero X-TRA 1420 aero. We only have 24H/24H, no 20H/24H. Is that ok for you? Nipples: Pillar PT 734. Do you like black, blue, gold, green or red? Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

B

Ben 2014/08/17

Is the $159 for one rim or the set? How is the lead time/price/shipping to USA for 2 rims: wider 700c 38mmm clincher cross rims are designed for cyclocross bike & road bike 32H 3K matte finish no brake track?

Light-Bicycle 2014/08/18

Hello Ben, Thanks for your inquiry. Please find the attached cross-section drawing of the 23mm wide 38mm depth clincher rim. It's OK to have 2pcs rims with 3k matte and 32H(no braking track). http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ The given price USD159 is for only 1pcs rim and the shipping cost is USD50 for 2pcs rims to USA by EMS. Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

L

Larry 2014/07/27

What is the INTERNAL width of the 700c 38mmm clincher cross rims?

Light-Bicycle 2014/07/28

Hello Larry, Thanks for your inquiry. The internal width is 15.4mm. Please find the attached cross-section drawing of the 23mm wide 38mm clincher rim. For the rims, do you prefer UD, 3k or 12k? Matte or glossy? Front 20H/rear 24H? http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Y

yogadizz 2014/06/08

Hai, I am interest of ordering your cx rim wih specs : 700c wide 38mm clincher Rims: matte(without braking track) -- please send me the difference of UD and 3k Hubs: red anodized Novatec D711 standard QR/ D702-135mm standard QR for sram/shimano 10/11 speed 32H Spokes: black bladed Pillar Aero X-TRA 1420 Nipples: Black anodized alloy - possible customized 2 spokes with red anodized each wheel? How much the delivery time and total shipping cost to Indonesia ? and how much add cost with additional decals?

Light-Bicycle 2014/06/09

Hello Sir, Thanks for your inquiry. Please find the attached cross-section drawing of the 23mm wide 38mm clincher rim. For 3k/12k/UD, it is the outer carbon fiber layer to make the carbon fiber with different outlook. It is only the outer layer different and all the inside carbon fiber are the same. So, the strength & weight is almost the same. 3k/UD & matte are more popular. For the rims(matte, 32H, no braking track), do you prefer UD, 3k or 12k? http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ You can let us know what kind of graphic you like for rims. Then we can make graphic file for your reference. For the extra cost for custom graphic, it's around USD60 with one color. There is red Novatec D711standard QR. For the D702-135mm standard QR, it's for campy10/11 speed. There are 2 versions of the D712-135mm standard QR, one is for Shimano 8/9/10 speed and another one is for Shimano 11 speed. Which one do you prefer? Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

P

Pedro 2014/05/12

I wonder the difference between Weave: 12K - 3K - UD? What are the rays of which intend to use a rim 24Hole well as the final price of the rim and spokes for Portugal. thank you Gostava de saber a diferen

Light-Bicycle 2014/05/13

Hello Pedro, Thanks for your inquiry. Please find the attached cross-section drawing of the 23mm wide 38mm clincher rim. For 3k/12k/UD, it is the outer carbon fiber layer to make the carbon fiber with different outlook. It is only the outer layer different and all the inside carbon fiber are the same. So, the strength & weight is almost the same. 3k/UD & matte are more popular. For the rim(24H), do you prefer UD, 3k or 12k? Matte or glossy? Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

J

joy 2014/04/20

In case of this 38mm clincher rim, please tell me each weight of "WITH brake track rim" and "WITHOUT brake track rim".

Light-Bicycle 2014/04/21

Hello Joy, Thanks for your inquiry. Please find the attached cross-section drawing of the 23mm wide 38mm clincher rim. It’s around 1~2g for the weight of braking track. The rim weight is 400 /-15g for a single rim. So, the they are almost the same for the rims with and without braking track. For the rims, do you prefer UD, 3k or 12k? Matte or glossy? Front 20H/rear 24H? Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

See all 24 customer reviews>>
