Custom Road Non-disc Wheels

We will discuss the MISSING INFORMATION with you by e-mail. Please find the instruction on the bottom for your reference.

WHEEL BUILDER
PRICE REFERENCE
HUB AVAILABILITY

PRICE REFERENCE CHART

*All price on the table is in US dollars.

Non-Pro Non-Disc

Hub BrandPrice
With High TG SurfaceWith Grooved Gaphene Surface
Novatec 460~680 510~740
DT SWISS 350 580~720 640~780
Hope 720~860 780~920
DT SWISS 240S 750~890 810~950
Chris King R45 1000~1140 1060~1200
Carbon-Ti 890~1030 950~1090
Extralite 1140~1280 1200~1340

DIFFERENCES BRIEFINGS FOR GROOVED GRAPHENE SURFACE / HIGH TG SURFACE

Non-Disc Grooved Graphene Surface


Graphene Brake Track : Graphene added to the rim brake track allows for greater resistance to overheating with improved heat dissipation and reduced temperature accumulation during heavy braking. The grooved track helps evacuate trapped moisture between pad and rim in the wet, and brings more resistance when conditions are dry so less force at the lever is required.

Non-Disc High TG Surface


High TG Surface: Rim Brake 700C road rims use an advanced High TG resin system with a layer of graphene to help dissipate heat. The braking power and reliability is significantly improved over a basalt braking surface.

If you are going for non-disc wheels applying the most advanced technologies but with a much better price, the grooved graphene surface stand out for you.

Or if you have a limited budget, wanting to have a pair of non-disc wheels competent to deliver decent performance on major occasions, the most cost-effective high TG surface support you there making your dream come true.

RIM LIST

700C(CLINCHER)

Model Depth(mm) External Width (mm)
R25 25 25
R35 35 25
R45 45 25
R55 55 25
R65 65 25.85
R88 88 26.54
AR36 36 28
AR46 46 28
AR56 56 30

700C(TUBULAR)

Model Depth(mm) External Width (mm)
R25T 25 25
R35T 35 25
R45T 45 25
R55T 55 25
R65T 65 25.85
R88T 88 26.54

HUB SPECIFICATION

*Hub weight: Take front 100mm QR/rear 130mm QR for reference

Carbon-Ti (non-disc)

Weight

220g

Color

Front size

  • 100mm QR

Rear size

  • 130mm QR

Description

ROAD rear hub with oversized Al7075-T6 CNC machined body and axle, external bearing preload system, Al7075-T6 free wheel Shimano/SRAM 10-11s compatible. Several anodized colours or mirror polished available. Made in Italy.

Extralite SP (non-disc)

Weight

177g

Color

Front size

  • 100mm QR
  • 15*100mm
  • 12*100mm

Rear size

  • 130mm QR
  • 135mm QR
  • 12*142mm

Description

Alternatively, consider CyberFront SL and CyberRear SL that offer the easiness of externally mounted standard elbow spokes and the widest possible camber of all spoke flanges.CyberFront SP features the widest possible spoke camber to offer higher lateral stiffness.It fits most road forks however few makers introduced bulge legs that reduce hub clearance. For that reason also we have introduced CyberFront SP-X that is still able to achieve that same high lateral wheel stiffness allowing a sensibly higher spoke tension.

Chris King R45 (non-disc)

Weight

317g

Color

Front size

  • 100mm QR

Rear size

  • 130mm QR

Description

Alternatively, consider CyberFront SL and CyberRear SL that offer the easiness of externally mounted standard elbow spokes and the widest possible camber of all spoke flanges.CyberFront SP features the widest possible spoke camber to offer higher lateral stiffness.It fits most road forks however few makers introduced bulge legs that reduce hub clearance. For that reason also we have introduced CyberFront SP-X that is still able to achieve that same high lateral wheel stiffness allowing a sensibly higher spoke tension.

DT SWISS 240s(non-disc)

Weight

321g

Color

Front size

  • 100mm QR

Rear size

  • 130mm QR

Description

Swiss precision engineering, machining and assembly together with clever detail solutions have made of the 240 what it is today: A legend. Featuring the latest refinements the 240 hubs are extremely lightweight and extremely durable. The Ratchet System is the best solution for a freewheel system, since it can transfer high loads while being super light. Just what athletes want: Perfect transmission of their power and the reliability allowing them to focus on the ride.

DT SWISS 350 (non-disc)

Weight

375g

Color

Front size

  • 100mm QR

Rear size

  • 130mm QR

Description

description: Whoever is looking for the most affordable high performance hubs available, should take a very close look at the 350 hub line-up. The same performance as its even higher end cousins comes with slightly less weight optimized parts to offer the same reliability at a much lower cost. Being available in all standards and for any application, the 350 hub is for those who maybe like to ride the trails a little more than drooling over catalogs and specs.

Hope RS4 (non-disc)

Weight

394g

Color

Front size

  • 100mm QR

Rear size

  • 130mm QR

Description

Sealed Stainless Steel cartridge bearings; Hub shell machined from forged aluminium billet; Unsurpassed reliability; Reduced drag ratchet mechanism; 44 point engagement (8 deg).

Novatec A291/F482 (non-disc)

Weight

298g

Color

Front size

  • 100mm QR

Rear size

  • 130mm QR

Description

The least expensive but decent value to get you into a carbon wheelset without breaking.
