wider carbon 24mm rim road bicycles 700c tubular


The product has been removed, you could find the similar new product by clicking ( RRU25T02 )
Use
road bike/cyclocross
Size
700C
Material
full carbon Toray T700
Type
tubular
Weight
290g+/-10
Spoke Hole
16H to 36H
Internal hole
customized
ERD
592mm
Outer width
23mm
Depth
24mm
Max weight limit
110kg
Max spoke tension
180kgf
Max tyre pressure
160psi
Finish
matte/glossy
Decal
Weave
Warranty
1 Year
Standard
En Standard
  • Precise layup
    Each rim carries its own layup schedule documents which are followed meticulously by the layup workers. Our Engineering team creates a unique fiber orientation which amplifies the desired riding characteristics for a given rim.
  • T700
    Constructed with premium Toray T700 carbon fiber. The best strength to weight ratio with no expense spared.
Each rim carries its own layup schedule documents which are followed meticulously by the layup workers. Our Engineering team creates a unique fiber orientation which amplifies the desired riding characteristics for a given rim.
Constructed with premium Toray T700 carbon fiber. The best strength to weight ratio with no expense spared.
Dan : (2017-04-05)
Hello- What spoke counts would build a reliable wheelset using the 24mm deep/23mm wide rims? I weigh 165 lbs. Thanks!
LightBicycle : (2017-04-06)
Hello Dan, Thanks for your inquiry. You are not a large rider. For road wheels, rims in 20H/24H will work for you. Thanks, Lightbicycle
Reply

Bobby : (2016-10-24)
Hi; I need 24mm deep tubular rim with 24 holes (RR24T02), for internal nipples. Is it available and how long would it take to manufacture and deliver to Canada? Thanks, Bobby
Light-Bicycle : (2016-10-25)
Hello Bobby, Thanks for your inquiry. We are able to manufacture the 24mm rim in 24H and with internal nipple hole. Please find attached picture, is that what you like? Thanks, Light-bicycle
Reply

paolo : (2016-01-12)
hello im from Italy I need rims for cyclocross, these rims are fine . I need two pairs of wheels . How should I buy rims ? Quanro cost me ? thanks
Light-Bicycle : (2016-01-15)
Hello Paolo, Thanks for your inquiry. Did you mean you like 4pcs 29er rims for cyclocross use? If so, we’d like to recommend the 27mm wide 29er clincher rim which is tubeless compatible. Please find attached rim profile. Thanks, Lightbicycle
Reply

Louis : (2015-07-12)
I would like to order 4 RRU35T02 25mm wide 35mm deep tubular rims without brake track for disc wheelset. Can you tell me if they are currently available, when they would ship, and the shipping cost to USA? Thank you.
Light-Bicycle : (2015-07-13)
ello Louis, Thanks for your inquiry. RRU35T02 (25mm wide U-shaped 35mm tubular rim): 370 /-15g, USD145/pcs Rims are without braking surface for disc wheels. Please find attached rim cross-section drawing. For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? 24H/24H? Please find below link. http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ Thanks, Light-bicycle
Reply

sebastian : (2015-06-21)
helllo from Slovenia do you shiping to slovenia?? i wanna know if its posibile to fit on this rims tabular 19mm??
Light-Bicycle : (2015-06-23)
Hello Sir, Thanks for your inquiry. Yes, we can ship our products to Slovenia. Don’t worry. We had some customers from Slovenia already. Sorry, do you mean that if the 24mm tubular rim can work with 19mm tires? Or you like the 19mm tubular rim? RR24T02 (23mm wide 24mm tubular rim): 320 /-15g, USD129/pcs Please find attached rim cross-section drawing. For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? 20H/24H? Please find below link. http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ Thanks, Light-bicycle
Reply

Bill : (2015-06-19)
hi all, are these rims in 30mm Depth 23mm wide available? 35mm U-Shape 25mm wide is to much for me! and 38mm - 23mm wide also. thanks a lot from berlin germany, bill
Light-Bicycle : (2015-06-23)
Hello Bill, Thanks for your inquiry. Currently, we only have 23mm wide 38mm depth & 25mm wide 35mm depth tubular rims, no 30mm depth rim. The 25mm width rim is much wider and stronger. Most of our customers chose this new one, and it is with nice feedback. We are sure that you will like it. RRU35T02 (25mm wide U-shaped 35mm tubular rim): 370 /-15g, USD145/pcs RR38T02 (23mm wide 38mm clincher rim): 340 /-15g, USD133/pcs Please find attached rims cross-section drawings. For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? 20H/24H? Please find below link. Thanks, Light-bicycle
Reply

Jamie : (2015-04-14)
Hi, Are these rims available for purchase? If so, what would be the cost of 1 rim, 18 hole in 3k gloss finish, shipped to Australia?
Light-Bicycle : (2015-04-15)
Hello Jamie, Thanks for your inquiry. Yes, the 24mm tubular rim is for sale. We also have new 25mm wide U-shaped 35mm tubular rim. It is much wider and stronger. Most of customers chose the new one. Would you like to have a try? RR24T02 (23mm wide 24mm tubular rim): 320 /-15g, USD129/pcs RRU35T02 (25mm wide U-shaped 35mm tubular rim): 360 /-15g, USD145/pcs Please find attached rims cross-section drawing. It is ok to do 18H & 3k glossy. Thanks, Light-bicycle
Reply

Jordy : (2014-04-18)
Hello, Can i order these rims with 24/28 spoke holes without braketrack? (Disc brake) gloss UD carbon
Light-Bicycle : (2014-04-19)
Hello Jordy, Thanks for your inquiry. Currently, the 23mm wide 24mm depth tubular rim is not available here.it is with 20.8mm wide. But there is 23mm wide 38mm depth tubular rim. Please find the attached cross-section drawing of rim. Is it OK for you? It’s OK to manufacture the rims with UD glossy and 24H/28H(no braking track). Thanks, Light-bicycle
Reply

michael : (2014-03-27)
Hi, just wondering if these are out of backorder. I notice that in February another customer asked when they will be available, do you have any updates? thx
Light-Bicycle : (2014-03-28)
Hello Michael, Thanks for your inquiry. Currently, the lead time of rim is around 15 business days. We already added a new product line but there will be a period of adjustment. The lead time would be around 8 business days since May. For the 23mm wide 24mm tubular rim, it’s still not available. But there is 20.8mm wide rim. Is it OK for you? Please find the attached cross-section drawing. Thanks, Light-bicycle
Reply

Alain : (2014-02-24)
Hello, The 24mm carbon tubular rim width 23 mm it available now ? or how long ? can give a date? I want to buy a pair of 24mm carbon tubular rims 23 width-20/24 holes-Internal nipples-12K matt finish Best regards, Alain
Light-Bicycle : (2014-02-26)
Hello Alain, The wide 23mm wide 24mm tubular rim is not available. It's hard to tell the exact time of availability. But there are 23mm wide 20mm and 38mm depth tubular rims. Please find the attached cross-section drawings. Is it OK for you? Thanks, Light-bicycle
Reply
