Build Your Recon Pro WHEELSET WMXC930-PRO

All wheels are 100% customizable at Light Bicycle. If your preferred specs are not listed, feel free to contact us (sales@lightbicycle.com) with your special requirements described.


Buy rim only

WHEELSET SPECS

RIMS

Our Pro series comes with a 5-year warranty (lifetime optional), while the non-pro with a 3-year warranty and crash replacement.

  • Model XC930-Pro
  • Material Toray T700 & T800 Premium Carbon Fiber
  • Size 29"/29er (ETRTO 622mm)
  • Intended Use Cross Country, XCO, XCM
  • Bead Type Hookless
  • Tubeless Capable Yes
  • Inner/Outer Width 30mm/35.6mm
  • Depth 22mm
  • ERD 592.4mm (not including nipple head dimention)
  • Rim Weight 255+/-15g
  • Profile Symmetric (3.3mm)
  • Max Cyclist Weight (on flat ground) 95kg/209lbs
  • Spoke Hole Angle ±7°
  • Spoke Tension 120~130kgf front disc side and rear drive side
  • Max Tire Pressure 35psi/ 2.77bar
  • Recommended Tire Width 2.35''~2.4''

HUBS

We keep in stock the most popular axle sizes and colors of some well-liked hub models. If you want a special order, feel free to contact us (sales@lightbicycle.com).

  • Model DT SWISS 180, DT SWISS 240 EXP, DT SWISS 350, Industry Nine Hydra, Industry Nine 1/1, Bitex BX212F / BX212R, Hope Pro 5
  • Front Axle Size 15 / 100mm, 15 / 110mm BOOST
  • Rear Axle Size 12 / 142mm, 12 / 148mm BOOST
  • Driver Body Shimano MTB 10/11S, Sram XD, Shimano MTB 10/11S Alloy, Sram XD Alloy, Shimano Micro Spline, Shimano Micro Spline Alloy
  • Hole 28H

OTHER PARTS

Leave a note at checkout or contact us if you want spare spokes or nipples.

  • Spokes Sapim CX Ray, Sapim D-light
  • Nipples Aluminium Black, Aluminium Red, Brass Oil slick, Brass Black

TECH

The XC930 Pro wheelset merges cutting-edge rim engineering with premium components for XC dominance. Anchored by the 255g Pro rim—featuring impact-resistant ULL layup—the system pairs reinforced spoke holes with hand-built reliability, maintaining tension stability under aggressive power transfers.

Customized with lightweight hubs and high-performance spokes, the wheelset slashes rotational mass for explosive starts and sustained climbs. A 35.6mm outer rim width and optimized bead hook enhance tire grip and pinch-flat resistance, while torsional rigidity ensures precision in technical descents. Built for podium chasers, it’s where grams saved become seconds earned.

Learn More >>

WARRANTY

For Non-Pro Series Rims: From the date of purchase, 3-year Standard Warranty.

For Pro Series Rims: From the date of purchase, 5-year Pro Warranty as standard and an upgraded optional lifetime Premium Warranty with minimum charge.

Crash Replacement: It is applicable with the same period as the warranty time range that you purchased for the rims with 10% /25% discount for Non-Pro series /Pro series.

Learn More >>


WHAT IS IN THE BOX


The XC930 Pro wheelset merges cutting-edge rim engineering with premium components for XC dominance. Anchored by the 255g Pro rim—featuring impact-resistant ULL layup—the system pairs reinforced spoke holes with hand-built reliability, maintaining tension stability under aggressive power transfers.

Customized with lightweight hubs and high-performance spokes, the wheelset slashes rotational mass for explosive starts and sustained climbs. A 35.6mm outer rim width and optimized bead hook enhance tire grip and pinch-flat resistance, while torsional rigidity ensures precision in technical descents. Built for podium chasers, it’s where grams saved become seconds earned.

  • Overview

    The XC930 Pro wheelset merges cutting-edge rim engineering with premium components for XC dominance. Anchored by the 255g Pro rim—featuring impact-resistant ULL layup—the system pairs reinforced spoke holes with hand-built reliability, maintaining tension stability under aggressive power transfers.

    Customized with lightweight hubs and high-performance spokes, the wheelset slashes rotational mass for explosive starts and sustained climbs. A 35.6mm outer rim width and optimized bead hook enhance tire grip and pinch-flat resistance, while torsional rigidity ensures precision in technical descents. Built for podium chasers, it’s where grams saved become seconds earned.
